The Factory Directly Sends Large Industrial Filtration Equipment Membrane Filter Press With Belt Conveyor

Diaphragm filter press matching equipment: Belt conveyor, liquid receiving flap, filter cloth water rinsing system, mud storage hopper, etc.

A-1. Filtration pressure: 0.8Mpa; 1.0Mpa; 1.3Mpa; 1.6Mpa. (Optional)

A-2. Diaphragm pressing pressure: 1.0Mpa; 1.3Mpa; 1.6Mpa. (Optional)

B. Filtration temperature: 45℃/ room temperature; 80℃/ high temperature; 100℃/ High temperature.

C-1. Discharge method - open flow: Faucets need to be installed below the left and right sides of each filter plate, and a matching sink. Open flow is used for liquids that are not recovered.

C-2. Liquid discharge method - close flow: Under the feed end of the filter press, there are two close flow outlet main pipes, which are connected with the liquid recovery tank. If the liquid needs to be recovered, or if the liquid is volatile, smelly, flammable and explosive, dark flow is used.

D-1. Selection of filter cloth material: The PH of the liquid determines the material of the filter cloth. PH1-5 is acidic polyester filter cloth, PH8-14 is alkaline polypropylene filter cloth. The viscous liquid or solid is preferred to choose twill filter cloth, and the non-viscous liquid or solid is selected plain filter cloth.

D-2. Selection of filter cloth mesh: The fluid is separated, and the corresponding mesh number is selected for different solid particle sizes. Filter cloth mesh range 100-1000 mesh. Micron to mesh conversion (1UM = 15,000 mesh---in theory).

E. Rack surface treatment: PH value neutral or weak acid base; The surface of the filter press frame is sandblasted first, and then sprayed with primer and anti-corrosion paint. The PH value is strong acid or strong alkaline, the surface of the filter press frame is sandblasted, sprayed with primer, and the surface is wrapped with stainless steel or PP plate.

F. Filter cake washing: When solids need to be recovered, the filter cake is strongly acidic or alkaline; When the filter cake needs to be washed with water, please send an email to inquire about the washing method.

G. Diaphragm filter press operation: Automatic Hydraulic Pressing; Automatic Filter Plate Pulling; Filter Plate Vibrating Cake Discharge; Automatic Filter Cloth Rinsing System.

H. Filter press feeding pump selection: The solid-liquid ratio, acidity, temperature and characteristics of the liquid are different, so different feed pumps are required. Please send email to inquire.
